LED Full Cutoff Wall Pack – Downlight Only, Selectable Wattage & CCT, DLC Premium

⬇️Spec Sheet Coming Soon

LED Full Cutoff Wall Pack – Downlight Only

This Full Cutoff LED Wall Pack is engineered for applications that require strict downward light control with zero uplight, making it ideal for projects governed by dark-sky ordinances, municipal codes, and light-trespass restrictions.

The full cutoff optic delivers focused, glare-free illumination exactly where it’s needed — on walkways, perimeters, and ground-level surfaces — without spilling light upward or onto adjacent properties.

Built for real-world job sites, this fixture features a rugged die-cast aluminum housing, sealed optical chamber, and field-selectable wattage and CCT to reduce SKUs and simplify installs. One fixture can be dialed in on-site to meet changing lighting plans or last-minute inspector requests.

Why Contractors Choose This Full Cutoff Wall Pack

• True full cutoff distribution for code-compliant exterior lighting

• No uplight, no glare, no light trespass

• Selectable wattage & CCT reduces inventory and truck stock

• Standard wall pack footprint for fast retrofits

• DLC Premium listed for utility rebate eligibility

• Durable outdoor-rated construction built for long service life

Available Output Packages (Select at Time of Purchase)

This fixture is offered in two selectable wattage packages. Wattage is adjusted in the field within the chosen package.

• 40W / 60W / 80W – Selectable
  Ideal for walkways, building sides, and lower mounting heights

• 80W / 100W / 120W – Selectable
  Designed for higher mounting heights, wider spacing, and brighter perimeter coverage

Key Features

Optical & Performance

• Full Cutoff Distribution – Downlight only, no uplight

• High-efficiency LED system for consistent coverage

• Uniform light pattern with reduced glare

Electrical

• 120–277V standard

• Optional 347–480V

• 0–10V dimming standard

Color Temperature (Field Selectable)

• 3000K – Warm White

• 4000K – Neutral White

• 5000K – Cool White

Construction & Ratings

• Die-cast aluminum housing

• UV-stabilized, impact-resistant lens

• IP65 rated – dust tight & wet location

• Operating temperature: -40°F to 113°F

• 5-Year Limited Warranty

Ideal Applications

• Commercial building perimeters

• Apartment & multifamily exteriors

• Walkways & pedestrian paths

• Schools & municipal facilities

• Parking lot edges & service areas

• Locations requiring dark-sky compliance
