LED Jelly Jar Light – 21W, 5000K, IP65

Product Description

This LED Jelly Jar Light is a compact, utility-grade fixture designed for commercial and light industrial applications where durability, wide coverage, and straightforward installation are required. It replaces traditional HID or incandescent jelly jar fixtures with a high-efficacy LED solution.

Built with a sealed IP65-rated housing and wide 160° beam angle, this fixture is well-suited for garages, corridors, basements, service spaces, and similar environments where uniform illumination and long service life reduce maintenance calls.

Key Advantages

• Wide 160° distribution for even, usable coverage
• 120–277V input simplifies use across mixed-voltage sites
• IP65-rated housing for wet and dusty environments
• Familiar jelly jar form factor for quick retrofits
• High-efficacy LED output reduces energy and maintenance costs

Configuration & Field Adjustability

• Wattage: Fixed 21W
• CCT: 5000K
• Dimming: 0–10V dimming leads present; dimming capability may be model-dependent
• Distribution: 160° beam angle
• Mounting: Bracket mount for wall or square pole; 1/2" NPT conduit entry supported

No field-selectable wattage or CCT is indicated for this model. Any adjustment features should be treated as optional or model-dependent.

Construction & Application Notes

• Housing: Heavy die-cast aluminum with powder-coated finish
• Lens: Tempered glass with steel protective wrap
• Ingress Rating: IP65
• Operating Temperature: -30°C to +45°C
• Typical Applications:

• Parking garages

• Corridors and stairwells

• Basements and utility rooms

• Service areas and lobbies

• Light commercial and industrial spaces

Optional Callouts (Spec-Supported)

• Input Voltage: 120–277V AC
• Certification: UL / cUL, DLC
• LED Source: Lumileds 2835
• Efficacy: ~120 lm/W (2520 lumens @ 21W)
• Warranty: 5-Year Limited Warranty
