LED Lay-In Troffer Light – 5-Wattage & 5-CCT Selectable, 125 lm/W, Damp Rated, DLC Premium

⬇️Spec Sheet Coming Soon

This LED Lay-In Troffer Light delivers flexible, high-efficiency illumination for commercial interiors, combining 5 selectable wattages and 5 selectable CCTs in a single fixture. Designed for recessed T-bar ceilings, it provides up to 125 lumens per watt, smooth 0–10V dimming, and DLC Premium certification for energy rebates and long-term performance.

The LED Lay-In Troffer Light is a versatile, high-performance solution for offices, schools, retail spaces, and general commercial interiors. With field-selectable wattage and color temperature, contractors can dial in light output and appearance on site—reducing SKUs while maintaining design flexibility.

Built with a durable aluminum housing and anti-UV frosted polycarbonate lens, this troffer delivers uniform, glare-controlled illumination while remaining damp location rated for use in restrooms, corridors, and other moisture-prone areas. 0–10V continuous dimming ensures compatibility with standard commercial lighting controls.

Available in 1×4, 2×2, and 2×4 sizes, this fixture installs easily into standard T-bar ceilings and supports optional 90-minute emergency battery backup for code-compliant egress applications. Backed by a 5-year warranty, this troffer is built for long service life in demanding commercial environments.

Key Features

Selectable Output & Color

• 5 Selectable Wattages (up to 50W max, size-dependent)

• 5 Selectable CCTs: 3500K / 4000K / 5000K / 5700K / 6500K

• Field-adjustable for maximum flexibility

High Efficiency Performance

• Up to 125 lumens per watt

• Output range: 1,875 – 6,250 lumens

Electrical

• 120–277V input

• 0–10V continuous dimming

• Power factor >0.9

• THD <15%

Construction

• Aluminum sheet housing with satin finish

• Anti-UV frosted polycarbonate lens

• Corrosion- and discoloration-resistant

Mounting

• Recessed T-Bar ceiling installation

• Fits standard grid ceilings

Environmental

• Damp Location Rated

• Operating temperature: -4°F to 113°F (-20°C to 45°C)

Emergency Options

• Optional 90-minute emergency battery backup

• Supports code-compliant egress lighting

Certifications

• DLC Premium

• ETL Listed (US & Canada)

• FCC & RoHS compliant

Warranty

• 5-Year Limited Warranty

Available Sizes

• 1×4

• 2×2

• 2×4

Ideal Applications

• Offices & conference rooms

• Schools & universities

• Retail stores

• Medical offices

• Lobbies & corridors

• Restrooms & back-of-house spaces

• Workstations & open offices

Performance Summary

• Input Voltage: 120–277V

• Efficacy: 125 lm/W

• CCT: 3500K–6500K (selectable)

• Dimming: 0–10V

• CRI: 83

• L70: 50,000 hours

• Location Rating: Damp
